SANTA CRUZ 2026 STIGMATA 4 CC GRAVEL FRAME SET

The Stigmata blurs the lines between free-roading drop bar singletrack slicer and buckled down race-winning gravel machine. It’s designed for the rider lining up for The Big Event, escaping via the road less traveled or who can’t help themselves from finding the hardest way there. Whether your style is baggy or zipped up, the Stigmata is the fast and loose riding partner that’s always ready to rise to the occasion.

Features

- CC Carbon Frame

- Progressive Geometry

- Glovebox

- Low Profile Fender Mounts

Build Kit:  FRAME SET ONLY

Specifications  (Subject to change without notice)

- Material: Carbon CC

- Frame: Carbon CC Gravel

- Weight: 4.12 lbs / 1.87 kg

- Wheel Size: 700C

- Bottom Bracket Shell: Threaded 68mm

- Rear Brake Mount: 160mm FM

- Fork Axle to Crown: 430mm

- Fork Compatibility: 40mm

- Fork Offset: 45mm

- Front Derailleur Mount: Clamp On

- Headset: Integrated (IS41/52)

- Max Chainring Size: 42t (1x) | 50t (2x)

- Max Tire Clearance: 50mm (1x) | 45mm (2x)

- Rear Spacing: 142mm

- Seat Clamp Diameter: 31.8mm

- Seat Post Diameter: 27.2mm

- UDH Compatible: Yes

- Water Bottle Mounts: 3

  BRITISH RACING GREEN

  MATTE CARBON
